UPPER UNIT PARTS
16
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2306957 Inverter Box
2 489373 Screw, Compressor
Mounting (4)
3 2302967 Compressor
(Includes Items
6, 9 & 21)
(Also Order
876765 Tube Kit)
4 2307683 Housing,
Control Board
5 2303091 Control Board
6 1100826 Grommet, Mounting
7 2309002 Support, Condenser
(Right)
8 2303033 Transformer
9 2215676 Terminal Cover
10 2309001 Support, Condenser
(Left)
11 2304135 Control Board
12 2203075 Spacer (9)
13 2256328 Bracket,
Inverter Box
14 8281149 Screw
15 1157158 Screw
16 2307998 Condenser
17 2309431 Grommet (2)
18 2187629 Wire, Jumper
19 489399 Screw
20 2155774 Wire Tie
21 2252363 Drier
22 2215641 Bracket, Fan Motor
23 2206036 Motor, Fan
24 2190685 Blade, Fan
25 2003169 Orifice, Fan
26 486692 Speed Nut
27 8281160 Screw
28 2317031 Bracket, Vibration
(Condenser)
29 2317030 Arm, Vibration
(Condenser)
30 2307566 Tube, Transition
(Condenser/Drier)
31 2194319 Tube, Process
32 486194 Screw
33 2309000 Cover, Condenser
34 2259197 Service Cord
35 2307684 Bracket, Mounting
(Power Switch)
36 549193 Clamp, Cord
37 2266802 Switch, Power
Disconnect
38 487294 Screw, Ground
39 2310179 Wiring Harness,
Unit Compartment
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
6.25 oz.
(R−134A)
