LOWER UNIT AND TUBE PARTS
18
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
1 2309072 Tube, Transition
(Condenser)
2 2309070 Tube, Transition
(Drier/Restrictor)
3 486194 Screw
4 2307944 Clip
5 2307945 Bracket, Mounting
6 2309076 Tube, Suction
7 2306176 Heater, Defrost
8 2306178 Scroll Assembly
9 2223986 Grommet, Motor
10 2259385 Motor, Fan
11 2223733 Retainer,
Fan Motor
12 2169142 Blade, Fan
13 2309073 Tube, Discharge
14 2310137 Defrost Bi−Metal
15 2306053 Evaporator
16 2316878 Heater, Drain Pan
17 2209450 Hanger, Heater
18 2005908 Shield, Drain Pan
19 2215648 Dampener, Heater
20 2316603 Shield,
Water Filter
21 2155774 Wire Tie
22 2317920 Clip, Heater
23 2001264 Drain Pan
24 Bracket, Drain Pan
1113206 Left
1113207 Right
