ICEMAKER PARTS
20
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
1 486194 Screw
2 2221240 Heater, Fill Tube
3 489136 Screw (2)
4 2310108 Jumper, Heater
Fill Tube
5 628379 Clip, Fuse
6 2214613 Tube, Filter Inlet
7 2317848 Tube Assembly,
Water Inlet
8 1106508 Seal Gasket
9 2316536 Tube,
Filter Outlet
10 2309417 Valve, Solenoid
11 2307792 Cover, Bottom
12 489464 Screw
13 2221231 Heat Shield
14 2307791 Mounting Bracket,
Water Valve
15 489348 Clamp, Valve
16 488946 Clamp, Tubing
17 2310136 Wire Harness,
Icemaker
18 2257538 Cover
19 626678 Module Assembly
(Includes Items
3 & 21)
20 628228 Mold & Heater
(Also Order
542638 Silicone
Grease)
21 626676 Motor
22 628356 Cup, Water Fill
23 627843 Ejector
24 2182124 Ice Stripper
25 2195914 Support
26 627796 Retainer,
Thermostat (2)
27 627985 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
29 489276 Screw
100 2316895 Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
8537055 Cleaner,
Stainless Steel
