KitchenAid KBFC42FSS00 - Page 6

REFRIGERATOR LINER PARTS
6
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
1 Liner,
Refrigerator
(Not Servicable)
2 2317004 Cover,
Air Return (2)
3 2309244 Control Box
(Complete)
4 2317000 Clip, Control Box
5 2317046 Bracket,
Light Shield
6 2309248 Shield, Light
7 487539 Screw, 8−15 x 1/2
8 488163 Screw
9 2223857 Socket, Light (3)
10 2309101 Bulb, Light (3)
11 2317917 Clip,
Diffuser Cover
12 2306499 Diffuser Assembly
13 2306480 Cover, Diffuser
14 2188820 Thermistor
15 2209204 Clip, Thermistor
16 1116793 Cover, Thermistor
17 2268249 Diffuser, Crisper
(Complete)(2)
18 2196483 Stud, Shelf
19 Spacer, Crisper
2268331 Left
2268332 Right
20 Spacer, Deli
2306475 Left
2306474 Right
21 Slide, Crisper Pan
2302952 Left (2)
2302953 Right (2)
22 Center Support
2313997 Left Half
2313996 Right Half
23 Slide, Deli Pan
2302956 Left (2)
2302957 Right (2)
24 2314054 Support,
Deli Cover (2)
25 2309083 Cover, Center
(Crisper Pans)
26 2318008 Cover, Center
(Deli Pans)
27
W10001160 Screw, 8−32 x 1/2
