KitchenAid KBFC42FSS00 - Page 8

FREEZER LINER PARTS
8
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
1 Liner, Freezer
(Not Servicable)
2 2306425 Mounting Bracket,
Drawer Slide (2)
3
W10071460 Screw
4 2309297 Drawer Slide,
Freezer Basket (2)
5
W10061370 Screw
6 2314022 Cover,
Light Switch
7 1118894 Switch, Rocker
8 486194 Screw
9 2223857 Socket, Light
10 2309101 Bulb, Light
11 2268299 Switch Assembly,
Icemaker
(includes emitter)
12 2306187 Cover, Wiring
(Icemaker)
13 2317005 Duct, Air Flow
(Icemaker)
14 2306100 Cover, Evaporator
15 2317829 Cover,
Evaporator Fan
16 487539 Screw
17 2306106 Spacer, Drawer
(Right Side)
18 Slide, Freezer Bin
2306117 Left (2)
2306116 Right (2)
19 488163 Screw
20 2317925 Divider,
Freezer Bins
(includes receiver)
21 2306104 Support, Slide
(Right)
22 2317927 Shield
23 2306105 Support, Slide
(Left)
24 Bracket,
Evaporator Cover
2320512 Left Side
2317893 Right Side
25
W10071540 Screw
26 2320513 Bracket,
Air Return
27 2209204 Clip, Thermistor
28 1116793 Cover, Thermistor
29 2188820 Thermistor
30
W10075920 Washer
31 2320526 Washer (EPDM)
32 8533928 Screw
33 2317943 Gasket,
Air Deflector
