KitchenAid KDDO24RVX00 - Cabinet Parts

CABINET PARTS
2
For Model: KDDO24RVX00
(Custom Panel Overlay)
W10233586
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10130022 Installation
Instructions
W10130023 Use & Care Guide
W10233837 Service &
Wiring Sheet
W10233839 Energy Guide
2 4344793 Screw
3
W10233777 Rail Assy.
4
W10233778 Support Shelf, LH
5
W10233779 Support Shelf, RH
6
W10233780 Support Rubber A
7 4344748 Ladder, LH
8 4344749 Ladder, RH
9 4344794 Screw
10 4344795 Washer
11
W10162986 Screw & Washer
12
W10204610 Defrost Heater
13 4344747 Heat Shield
14
W10204621 Thermal Fuse Assy.
15
W10204630 Lead Wire Support
16
W10204632 Liner Bushing
17 Cabinet (Not a
Servicable Part)
