KitchenAid KERA807PSS - Page 70

7-6
L1
BK
BK
BK
2
ELEMENT 1800 W
BR
W
1B
2A
2B
1A
L1
LED CONSOLELIGHT
LED
N
W
Y
BR/W
BR
W
N
R
L2
W
FROM P4-6
POWER BOARD
BK
3
1
SURFACE INDICATOR LIGHT
SMART KNOB SWITCH
COOKTOP ELEMENT
2
1
BU
W
L1
L1a
SURFACE ELEMENT (SINGLE)
COOLING FAN
K10 COOLINGFAN RELAY
GY
P4-5
M
COOLINGFAN 60 W
W
BK
GY
GY
THERMAL SW CLOSES @ 70
° C ± 3 ° C
(158
° F ± 5.4 ° F)
W
N
POWER BOARD
L1
BK
BK
P4-1
BK
