KitchenAid
®
Food Processor Service/Repair Manual
Intended for Professional Service Technician Only
© 2016 KitchenAid
®
Covers Domestic Model – 13-cup: KFP1322ER, KFP1333WH, KFP1333OB, KFP1333ER, KFP1333CU,
KFP1333BD, KFP1333GC, KFP1333QG, KFP1333ACS, KFP1344CA, KFP1344ES, KFP1344MS, KFP1344ACS,
KFP1344ACS, KFP1344AES, KFP1344ACA, KFP1344AFPO, KFP130CU, KFP1330SPO, KFP1355WH,
KFP1355OB, KFP1355ER, KFP1355BU, KFP1355CU, KFP1355GC, KFP1356BU, KFP1356CU, KFP1356ER,
KFP1356GA, KFP1356WH, KFP1356TG, KFP1356OB
International Model – 3.1L 5KFP1333GER
Table of Contents
Subject Page(s)
Important Service Workplace Safety Recommendations 1
Service Environment 2
Personal Protection 2
Electrical Considerations 2
Electrical Requirements 3
Important Safeguards 3
List of Tools Required 4
Testing the Food Processor 4
Service Procedures: 6
Component Access (Housing Base Removal) 6
Remove Power Cord 8
Remove Slicing Disc Adjusting Knob 9
Remove Motor 10
Remove Control Board 11
Re-Assembly of the Unit 11
Motor Replacement 12
Control Board Replacement 12
Cord Replacement 13
Clean and Test Unit 14
Appendix Subject Page(s)
A Tools Required for Food Processor Service 15
B Problem Guide 16
C 13-cup Food Processor Screw Torques 17
