KitchenAid KFRU488TSS00 - Grill Parts; Literature Parts; Main Grill Components; Hood and Tray Parts

GRILL PARTS
2
For Models: KFRU488TSS00
(Stainless Steel)
W10146425
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10110725 Use & Care Guide
W10110730 Conversion Instr.
(LP to Natural)
2
W10128619 Cover, Rear
3
W10140249 Panel, Rear
4
W10140252 Panel, Access
5
W10128634 Bracket, Panel
Left
6
W10128635 Bracket, Panel
Right
7 Bracket, Warming
Rack
W10128636 Left/Right
W10140243 Middle
8
W10128637 Cover, Access
Panel
9
W10128638 Clip, Wire
10
W10140260 Hood Assy
11
W10128640 Hole Plug
12
W10137906 Panel, Side Left
13
W10128644 Bracket, Grease
Tray (Right)
14
W10128655 Roller, Drip Tray
15 Drip Tray Assy
(Includes Rollers)
W10133870 Large
W10140262 Small
16
W10128657 Bracket, Grease
Tray (Left)
18
W10132690 Cover, Wire
Terminal
19 Bushing
W10132691 Plastic (#SB22)
W10132692 Plastic (#SB19)
21
W10140245 Harness, Wire
Light
24
W10128751 Nameplate
25
W10134821 Knob, Main Burner
26
W10134822 Knob, Rear Burner
27
W10134820 Bezel, Knob
28
W10128761 Switch, Light
29
W10140266 Panel, Control
30
W10140236 Harness, Wire
Control
31
W10140234 Valve, Main Brnr
32
W10128766 Valve, Rear Brnr
34
W10140213 Manifold
35
W10140251 Baffle, Front
37
W10132700 Side Panel, Right
38
W10137909 Panel, Outer (RT)
39
W10128660 Bar, Handle
40
W10128777 Thermometer
41
W10128779 Bezel, Thermometer
42
W10140254 Panel, Grease Tray
44
W10140208 Handle, Hood
45
W10128785 Endcap, Handle
(Left)
46
W10128786 Spacer, Handle
47
W10128787 Endcap, Handle
(Right)
48
W10128788 Hinge, Lid
49
W10140259 Hood
50
W10134987 Transformer,
Rotisserie Motor
51
W10134988 Bracket, Spit
52
W10128659 Bracket, Handle
53
W10136946 Shelf, Side (LF)
54
W10136956 Bar, Tool
55
W10132695 Brkt,Trnsfrmr(Btm)
56
W10132702 Regulator (NG)
57
W10128747 Fixture,Manifold
58
W10128748 Connector (Brass)
59
W10128749 Base, Manifold
Fixture
60
W10140247 Harness, Wire
61
W10134981 Fork, Spit
62
W10140240 Rod, Spit
63
W10134985 Motor, Rotisserie
64
W10134986 Bracket, Rot. Mtr.
65
W10137901 Valve, Sear Burner
66
W10137902 Valve, Side Burner
67
W10140228 Nut, 1/4"
68
W10140218 Screw, 1/4 x 35
