KitchenAid KFRU488TSS00 - Base Parts Continued; Condiment Tray and Door Components; Battery and Igniter Parts; Manifold and Control Components

BASE PARTS
4
For Models: KFRU488TSS00
(Stainless Steel)
W10146425
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 W10128666 Ring, Rubber
2
W10128667 Box,Transformer
3
W10128668 Cover,Transformr
Box
4
W10134823 Transformer
5
W10128670 Clamp, Wire
6
W10137896 Panel, Rear
7
W10128672 Caster
8 Panel, Bottom
(Not Serviced)
9
W10128674 Bracket, Tank
Tray (Right)
10
W10128675 Bracket, Tank
Tray (Left)
11
W10137890 Slide, Tank Tray
12
W10128677 Bolt, Tank
13
W10140270 Tray, Tank
14
W10128679 Lock, Tank Tray
15
W10128680 Handle,Tank Tray
16
W10128681 Bracket, Towel
Rack
17
W10128686 Rack, Towel
18
W10136429 Tray, Condiment
19
W10140267 Door, Left
20
W10128696 Hole Plug
21
W10128697 Magnet, Door
22
W10136431 Door, Right
23
W10128703 Bag, Lighting Rod
24
W10128704 Rod, Lighting
25
W10140241 Caster, W/Brake
26 Panel, Side Assy
(Not Serviced)
27
W10128711 Cover, Battery
Box
28
W10128715 Box, Battery
29
W10128719 Case, Battery
Box
30
W10137895 Regulator
31
W10128747 Fixture, Manifold
32
W10128748 Connector (Brass)
33
W10128749 Base, Manifold
Fixture
34
W10128750 Commutator,
Manifold
35
W10128661 Handle, Door
36
W10128659 Bracket, Handle
37
W10136427 Rack, Storage
38 Bracket
W10137885 Left
W10137889 Right
39
W10137886 Plug, Door
40
W10140268 Drawer, Top
41
W10137888 Slide, Drawer
42 Gaurd, Tank Tray
W10137892 Left
W10137893 Right
43 Partition, Cart
(Not Serviced)
44
W10140256 Partition, Left
45
W10140215 Screw, 1/4 x 12
