4
Installation diagrams
180 mm 280 mm
180 mm 145 mm
Min. 5 cm
Min. 10 cm
Min. 3 cm
Max. 6 cm
MODEL KHIS 7720 FOR MODEL KHIF 7720 ONLY
(flush installation)
