6. Wash the dispenser assembly parts in warm soapy water – do
not use abrasive cleansers or scouring pads. Use the large end of
the provided cleaning brush to clean the interior of the
dispensing cylinder. Rinse the parts with clean water and let dry
thoroughly. The dispenser assembly parts can also be washed in
the top rack of a dishwasher.
Assemble the Dispenser Assembly
1. Apply a light coating of vegetable oil to the O-rings on the
dispensing piston. This will lubricate the piston and make sliding
it into the dispensing cylinder easier.
4. Remove the dispensing lever clevis pin by pulling on the attached
ring, and lift the dispensing lever from the assembly.
5. Grasp the bottom of the dispensing cylinder and the top of
the dispensing piston, and pull the piston from the cylinder.
Continued…
45
Lubricate O-rings
with Vegetable Oil
CARE AND CLEANING
