Stand Mixer Service Manual LIT4177310-C 2005 KitchenAid
.
Appendix - A
Tools Required for Stand Mixer Service
Mallet
Hammer
Needle Nose Pliers
Ratchet
#3 Phillips
Bit
11/32” Wrench
Long Flat Screwdriver
Short Flat Screwdriver
3/8” Hollow Shank Nut Driver
5/32” Drift Punch
Volt / Ohm Meter
Watt Meter
Electronic Speed
Measuring Device
#2 Phillips Screwdriver
Cradle - Make your
own from wood,
cushion with cloth to
avoid damage to finish
of mixer.
A
B
C
D
E
E
A - 7”
B - 11”
C - 3”
D - 1 1/2”
E - 45 Degree
Angle
F - 1 1/2”
G - 3/4” Plywood
(8” x 11”)
F
G
Other Helpful Tools
1/2” Socket
Awl or Pointed Punch
