KitchenAid KRFC300ESS - Door Removal and Replacement

888888
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
Door Removal and Replacement
Top Hinges
A. Hinge Cover Screw
B. Top Hinge Cover
C.
5
/ 16 " Hex Head Hinge Screws
D. Top Hinge
B
A
C
D
A. Shim (on some models)
C. Hinge Screws
B. Bottom Hinge
Bottom Hinges
Wiring Plug
A
B
C
1
A.
3
/ 32 " Setscrew
A.
3
/ 32 " Setscrew
2
Drawer Front Removal
A. Loosen 4 Door Bracket Screws
A
Drawer Front Replacement
A
A
