12
FREEZER DOOR PARTS
For Models: KSRV22FVWH01, KSRV22FVBT01, KSRV22FVBL01, KSRV22FVSS01, KSRV22FVMS01
(White) (Biscuit) (Black) (Stainless) (Monochromatic Stainless)
W10246564
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(Includes Item 8
And Dispenser
Front Parts)
W10214818 White
W10214815 Biscuit
W10214814 Black
W10214817 Stainless
W10214816 Monochromatic
2 Handle
(Includes #4)
2319727W White
2319727T Biscuit
2319727B Black
2319727S Stainless/Satina
3 2308091 Thimble−Top
4 488208 Screw
5 2219698 Stud, Handle
6 2156021 Trivet (3)
7 3400012 Screw
8 Door Gasket,
Magnetic
2309604 Mist Beige
2309654 Black
2327162 Grey
9 2212375 Trim, Door Shelf
10 2182178 Door Closer,
Upper Cam
11 489420 Screw
12 Bracket, Door Stop
2323534 Chrome
2323534B Black
13 Set Screw
W10010140 Chrome
W10010150 Black
