KitchenAid KSSC48QMS01 - Dispenser Front Parts List

DISPENSER AND FRONT PARTS
20
For Model: KSSC48QMS01
(Stainless Steel)
8199056
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 2195051 Strain Relief
3 2187755 Wire Harness
4 Cover, Dispenser
(Not Available
Order #25)
5 2256199 Spring, Torsion
6 2196195 Pin
7 2206423 Ice Door Mechanism
8 2180353 Door, Ice
9 489000 Screw
10 2259396B Lever, Ice
Dispenser
11 Switch Assembly
(Not Available
Order #25)
12 2259395B Lever, Water
Dispenser
13 2194719 Spring, Lever
14 2205686 Delay Mechanism
15 2183771 Bracket, Control
16 2162361 Switch (2)
17 2259209 Bracket,
Anti−Drip Valve
18 2180200 Lamp Holder
19 488500 Screw
20 2187623 Wire Assembly
21 2180224 Guide, Ice
22 3406124 Light Bulb
23 2302944B Grille, Overflow
24 Overlay, Cover
(Not Available
Order # 25)
25 2306001B Front Cover
Assembly
(Includes Items
4, 11, 20 & 24)
26 2257420 Valve, Anti−Drip
27 2252127 Sleeve, Delay
Mechanism
28 2306077 Spacer, Dispenser
Cover
29 8281163 Screw
