KitchenAid KSSC48QMS01 - Refrigerator Liner Parts List

6
REFRIGERATOR LINER PARTS
For Model: KSSC48QMS01
(Stainless Steel)
8199056
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2302992 Spacer,
Air Baffle
3 2208970 Air Duct
4 2209204 Clip, Thermistor
5 2259077 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 2006475 Screw
8 486194 Screw
9 2306010 Thermistor
10 2302986 Lid, Baffle
Meat Pan
11 2302987 Baffle Control
Assembly
12 2171846 Release Valve
13 2187619 Harness, Air
Baffle
14 488357 Screw
15 2302937 Thermistor
17 2221296 Air Baffle
Assembly
18 2209687 Reservoir
19 488280 Screw
20 2259412 Seal, Air Duct
(Round Hole)
21 2208997 Diffuser Assembly
22 1116793 Cover, Thermistor
23 2188820 Thermistor
24 2259398 Seal, Air Duct
(Square Hole)
25 2215728 Cover, Diffuser
26 2259066 Cover, Air Return
27 487539 Screw
