PARTS AND FEATURES
This manual covers several different models. The features on your dishwasher may vary from those shown below.
A. Upper spray
B. 2-Position top rack adjuster (two)
C. FLEXI-FOLD DOWN™ flexible tines
D. Removable top rack
E. SATINGLIDE
®
upper rack track
F. Model and serial number label
G. Water inlet opening (in tub wall)
H. Removable rack inserts (three)
I. 4-way HYDRO SWEEP™
spray arm
J. Bottom rack
K. Detergent dispenser
L. Vent (on some models)
M. Active vent (Model KUDS01FL)
N. SURE-HOLD
®
utility shelf
O. Top rack
P. FLEXI-SPLIT™ divided tines
Q. SURE-HOLD
®
light item clips
R. Middle spray arm
S. Silverware basket
T. CULINARY CADDY
®
utensil basket
U. Overfill protection float
V. Heating element
W. SURE-HOLD
®
mesh sack
X. Rinse aid dispenser
Y. WHISPER QUIET
®
sound
insulation system
Z. Control panel located on door front
(Model KUDS01IL)
AA. Control panel (Model KUDS01DL)
BB. Control panel
(Models KUDS01FL, KUDS01VM)
F
G
H
I
J
K
B
L
C
D
E
A
N
T
U
V
W
X
P
R
S
Q
0
M
Y
Z
B
AA
