8
Medium rack insert
The medium rack insert when in the position as shipped, allows
you to wash a number of medium plates, and bowls. With the
small insert removed, you can move this insert forward in the rack
to wash another row of large plates.
Small rack insert
The small rack insert allows you to wash smaller plates, saucers,
and bowls. When you remove this insert, you have more flexibility
when moving the medium insert forward or back to wash larger
items.
Removing rack inserts
To remove large and medium inserts
1. Pull handle out to the right and lift up to release.
2. Lift insert out of rack.
To remove small insert
1. Pull out toward the back of rack and lift up to release.
2. Lift insert out of rack.
NOTE: It will be easier to install the inserts if you remove the
silverware basket from the rack.
Installing rack inserts
To install large insert
1. Place the large insert end legs under the 2nd from the right
wire as shown below.
2. Make sure that the three hooks on the back of the insert are
placed over the back wire in the bottom of the rack.
3. Push down on insert until handle fits against outer rack edge.
4. When center tab under handle locks in under the middle side
rack wire, the insert is in place. (See illustration.)
Insert placement for 2 rows of large plates.
B
B
A
C
Front view from inside rack
