Part
Number
Part (description)
Warranty
Coverage
Quantity
Part
Number
Part description)
Warranty
Coverage
Quantity
59
Spit fork 1 2 94
Door hinge
1 4
60
Spit rod 1 1 95 Door hinge support bracket 1 1
61
Rotisserie motor 1 1 96 Side panel, right 1 1
62
Rotisserie motor bracket 3 1 97 Door 3 1
63 Shaft Collar 1 1 98 Door Handle 1 3
64
Side burner lid hinge rod 1 2 99 Gas tank tray slide bracket, right 1 1
65
Side burner lid 3 1 100 Gas tank tray slide 1 2
66 Side burner lid hinge rod pin 1 2 101 Tank bolt 1 1
67 Side burner bowl assembly 3 1 102 Gas tank tray 1 1
68 Side burner 1 1 103 Gas tank tray block piece 1 1
69 Side burner ignition wire 1 1 104 Gas tank tray slide bracket, left 1 1
70 Side burner cooking grid 3 1 105 Drawer slide 1 2
71
Side burner front panel
3 1 106 Small door 3 1
72 Lamp cord 1 1 107 Drawer 3 1
73 Heat shield, right 1 1 108
Swivel caster with brake
1 1
74 Igniter wire cover A 1 1 109
Swivel caster
1 1
75 Rear panel 1 1 110 Bottom panel 1 1
76
Rubber grommet
1 2 111
Caster
1 2
77
Power cord buckle
1 1 112
Manual
78
Igniter wire cover B
1 1 113
NG conversion Kit
NG conversion kit sold
separately as a set
79 Transformer 1 1 113a NG regulator assembly for NG unit 1
80
Electronic igniter modular
1 1 113b
NG Gas Hose with Quick Connector
assembly for NG unit
1
81
Clapboard B
1 1 113c
6mm Nut Driver
1
82
Heat shield, left
1 1 113d
Hex Wrench
1
83
Door hinge support bracket
strengthen piece
1 2 113e
6mm Wrench
1
84
Firebox support piece A
3 1 113g
Truss Head Screw
2
85 Drawer support piece 1 1 113f
Flat Washer
2
86 Small door support piece 1 1 114 NG orifice pack 1
87 Side panel, left 1 1
114a
Side burner NG orifice (1.7mm)
1
88 Cart frame 1 1 114b Rear burner NG orifice (1.84mm) 1
89 Clapboard A 1 1 114c Sear burner NG orifice (1.98mm) 1
90 Door magnet 1 2 Preassembly hardware pack 1
91 Cart frame, middle 3 1 1
92
Lighting rod cover
1 1
93 Lighting Rod 1 1
12
118
Firebox connecting bracket
