12 13
Output RMS: 90 W
Satellite drivers:
3" 20 W
@
4 ohm x 2
Subwoofer:
6.5" 50 W
@
4 ohm
Output (1 kHz
@
1 m):
approx. 103 dB
S/N:
>
75 dB
Frequency response: 30 Hz – 20 kHz
Bluetooth: V4.0
Bluetooth range: up to 10 m
Aux-in: RCA
Aux-out: RCA
Unit size: H115.5 x W420 x D280 (mm)
Weight: 5.8 kg
Charging your device
• To do this, you will need a USB cable which is compatible with your device (not supplied)
• Connect the USB end to the USB charge socket (C)
• Connect the other end to your device
Tweaking the sound
• Press either the Bass (5) or the Treble (6) button
• Use the volume wheel to increase or decrease depending on your personal taste
• Then press either the Bass (5) or the Treble (6) button or wait for a few seconds for the volume wheel to return to being a volume wheel
To connect additional speakers (or even another Boom Evolution)
NOTE: This will only work if the speakers are self amplified.
• Make sure both systems are off and disconnected from the mains
• Locate the aux input on the other speaker
• Identify the type of connection
• Select the correct cable
• Connect one end of the cable to the aux-out (E) on the Boom Evolution
• Connect the other end of the cable to the aux-in on the speakers
• Turn everything back on
NOTE: It is possible to connect several Boom Evolution speakers together for huge sound.
It is possible to connect a wireless transmission dongle to the aux-out of one Boom Evolution.
It is possible to connect the receiver for that transmission dongle to the aux-in of another Boom Evolution.
The output level of the aux-out will be affected by the volume level of the device you are using.
Specifications
