Kitvision Edge HD10 - Page 5

8 9
Functions
1. TFT display screen
2. MENU key
3. Up key
4. Left key
5. Down key
6. Recall key
7. OK key
8. Push button
9. Lanyard hole
10. Microphone/Speaker
11. SD card slot
12. Right key
13. AV output interface
14. Record button
15. Indicator light (video/voice recording)
16. Power switch
17. Microphone
18. Red indicator light (on/charging)
19. LCD segment screen
20. Shutter
21. Stop key
22. Camera Lens
23. Green indicator light
(video recording/shooting)
24. HDMI output interface
25. USB output interface
26. Threaded mount hole
1
2
4
12
5
13
3
11
24
25
6
14 15 16 17
23
18 19 20 21
8 9 10 267
22
