Kitz 150 SCTBZ Series User Manual

DocumentNo.：KE-1027-00                                       Sheet:6/29

Ⅱ ValveOperatingDevice

2. WormGearOperator

2.1 Thewormgearoperatorismountedonthevalve.

2.2 Accordingtothearroworletteronthehandwheel,turningthehandwheelclockwisecloses
thevalve,andturningthehandwheelcounterclockwiseopensthevalve.

2.3 Handwheeloperatingtorquedependsonthesizeandopeningposition.

2.4 Wormgearoperatoristotransmitalargetorquetovalvestems,convertingatorquefrom
driveshaftbymeansofreductiongearingunitusingwormgears.


.




Kitz 150 SCTBZ Series Specifications

General

Brand	Kitz
Model	150 SCTBZ Series
Category	Control Unit
Language	English
