Klarstein 10035819 - Device Control Panel

19
EN
Button panel
Display panel
1 2 3 4 5 6
1 ON/OFF button
2 SPEED button
3 SWING button
4 TIMER button
5 COOLER/HUMIDIFIER button
6 MODE button
1
3 4 5
6
7
8
9
10
11
12
13
2
1 Remote control receiver
2 ON/OFF
3 Timing/temperature display
4 Temperature
5 Timing
6 Sleep wind mode
7 Natural wind mode
8 ECO mode
9 One light ON (low level)
10 Two-light ON (medium level)
11 Three-light ON (high level)
12 Swing
13 Humidication/cooling
