INSTALLATION
When install a Heat pipe Refrigerator, ventilation should be considered seriously, please
refer to the following:
• There should be left at least 200 cm³ for ventilation
• The distance between wall and refrigerator side should be at least 20mm
• The bottom should be left at least 50mm for air owing
• Air passing through must not be preheated
• Entire cooling system should be considered in the ventilation
the following four pictures show four installation ways:
