STEP 1:
• Place the hinge cup into the pre-drilled hole on the back of the door front.
• Use a mallet to tap in the hinge to the door as shown in the illustration. Place a piece of cardboard between the
mallet and door as needed to protect the door finish. To secure, tighten the screws with a Phillips screwdriver.
STEP 2:
• Mounting plate for hinges will be installed on the back side of the cabinet next to the cabinet opening. Mounting
plates will install, horizontally, in the row of pre-drilled holes 2nd from the top and bottom.
• Line up the 2 screws horizontally with the pre-drilled cabinet box holes. Secure the base plate into place using a
Phillips screwdriver.
CLASP
HINGE CUP
DOOR FRONT
