Klein + Hummel CMS 62 T - EC Declaration of Conformity; Other Information; Technical Specifications

14
EC Declaration of Conformity
This equipment is in compliance with the essential requirements and other relevant provisions of
Directives 2004/ 108/ EG and 2006/ 95/ EG. The declaration is available on the internet site at www.klein-
hummel.com. Before putting the device into operation, please observe any respective country-specific
regulations.
Other Information
Recycling
Attention to product quality in the design phase ensures, firstly, that products have a long life and that,
secondly, all parts of a product may be reused or recycled at the end of that life. An extensive product
servicing network ensures that products can be repaired in the event of the premature failure of a part, or
as a way to prolong the life of a product that would otherwise be considered a candidate for landfill.
Eventually there comes a time when a product is considered beyond repair (for economic reasons or lack of
parts), so the parts must be disposed of in a suitable manner. The disposal should conform to local
environmental regulations and be conducted in an authorized recycling facility. This product consists of
some or all of these components:
Item Material Recycling Instructions
Loudspeaker Steel, Plastic, Copper,
electronic devices
Recycling only in authorized
recycling plants
Packing Material Cardboard, wood and/or
plastics
Separate materials then recycle
User Manuals and Sales Literature Paper and cardboard Recycle
Technical Specifications
CMS 62 T
TECHNICAL DATA
Driver Sizes and Types 6.5“ LF + 1“ HF
Frequency Response (+/- 3 dB) 85 Hz to 19 kHz
Frequency Response (-10 dB) 65 Hz to 22 kHz
Sensitivity of loudspeaker system with passive crossover
(halfspace) 89 dB/1W/1m
Coverage Pattern, nominal 110 degrees conical
Directivity factor (Q) avg. 125 Hz - 16 kHz / avg. 800 Hz - 16 kHz
- 6.0 / 8.2
Directivity index (DI) avg. 125 Hz - 16 kHz / avg. 800 Hz - 16 kHz
7.8 dB / 9.1 dB
Passive Crossover point, slope and type LF/HF: 3500Hz - 2.order
Impedance of passive crossover 16 ohms nominal
Maximum SPL: 110dB SPL, Peak: 113dB SPL
Power Handling:
60 watts rms, 120 watts program, 240
watts peak (10ms)
Cabinet Material metal backside can
Cabinet Finish white
Weight 3.5 kg (7.7 lbs)
Depth 320 mm / 12.6 “
Baffle cut-out 285 mm /11.22“
Depth 200 mm / 7.89”
Connectors 4-Pin Phoenix connector
