Active Studio Monitor O 110 Page 9
4. Technical Specifications O 110
Maximum SPL
in half space, 3% THD at 1 m distance 107.7 dB/SPL
averaged between 100 Hz and 6 kHz
Free field frequency response 58 Hz - 20 kHz ± 2 dB
Self generated noise level at 10 cm < 20 dB(A)
Total Harmonic Distortion
150 Hz and above @ 1 m < 0.5 % @ 90 dB/SPL
Directivity Horizontal ± 40° (-6 dB)
Vertical ± 30° (-6 dB)
Electronics
Power amplifiers
Bass amplifier 50 W at 6 Ohm (THD < 0.1 %)
Treble amplifier 50 W at 6 Ohm (THD < 0.1 %)
Crossover section
Crossover frequency 2.5 kHz
Crossover slopes 24 dB / octave
Protection circuit against overload of both drivers
Input
Impedance 14 kOhm (electronically balanced)
14 kOhm (transformer balanced floating)
Sensitivity + 6 dBu
Volume control continuously variable from 0...-24 dB
Common mode rejection ratio > 50 dB @ 15 kHz
Equalization
4 position switch positioning on mixing console 0; -1.5; -3; -5 dB
4 position switch positioning on rear/side walls 0; -2.5; -5; -7.5 dB
Drivers magneticallay shielded
Bass 5.5” Ø, Composite - Sandwich - Diaphragm
Treble 1” Ø, Titanium Fabric Dome Tweeter
Connectors Mains 3 - terminal Euro connector
Signal input XLR connector 3-pin female
Power consumtion
Idle 10 VA
Full power 70 VA
Mains 230 V AC, 50/60 Hz, other voltages on request
Dimensions (W x H x D) 170 x 267 x 190 mm
Volume 8.6 liters
Weight 5.0 kg
Cabinet finish enamel charcoal-grey RAL 7021 or white RAL 9010
Accessories LH 31 mounting bracket
LH 28 tripod bushing (LH 31 mounting bracket required)
LH 29 TV - spigot (LH 31 mounting bracket required)
LH 27 ball clamp mount (LH 31 mounting bracket required)
LH 7 or LH 8 adaptor (LH 31 mounting bracket required)
LH 32 wall bracket
C 15 eyebolt
KG 30 ball clamp mount
