Quickstart
Security check:
Before starting the bike please always check the operation of
the brakes and the tyre pressure.
Launch of the electric drive
To start the propulsion system the display must be mounted
in the bracket. There are two ways to activate the system:
1. Press and hold for 1 second the start button (Image 3) –
the system runs for 3 sec through a systems check - now the
system is activated.
or
2. When You start pedalling the system will wake up
automatically. After 3 sec. of system check, the electrical drive
will support you.
Use the + (top left) and - (bottom left) buttons to select the
desired level of support. The support level is indicated by
the 3 horizontal bars at the top of the display.
0 bar UL (Ultra Low) No support; system is
activated
1 bar L (Low) Low support
2 bars M (Medium) Medium support
3 bars H (High) High support
The Walk/Turbo(á) button has 3 functions:
1. Walk-assist when walking next to your Speed Pedelec.
2. Turbo WITHOUT pedalling of the cyclist
3. Turbo WITH pedalling of the cyclist
1. Actuate the Walk/Turbo (á) button when walking
next to your vehicle. The maximum speed depends on
the selected support rate in your display. Therefore, we
recommend to use the Walk-assist mode only when
you selected the L support rate.
< 4 km/h Pushing aid while
taking your Speed
Pedelec by the hand
2. Turbo mode WITHOUT pedalling of the cyclist. The
maximum speed depends on the selected support rate
in your display.
At L < 4 km/h
At M < 12 km/h
At H < 18 km/h
Additional support at
standstill or in case you
do not want to pedal
3. Turbo mode WITH pedalling of the cyclist.
When actuating while riding in L support rate
When actuating while riding in M support rate
When actuating while riding in H support rate
L < 45 km/h
H (High)
H (High)
Not applicable
Additional support
while riding hills or
strong headwinds
Caution! We recommend that you use the Walk-assist
mode only in case you also selected the L support rate.
