Page #9 background imageLoading...
Page #9 background image
Headphone
Optical
Soundbar
TV
Digital Audio Out
3
1
2
Soundbar
TV
2
Audio Out
R
L
1
Soundbar
TV
2
1
4
3
4
4
3
3.5mm TO DUAL RCA ANALOG CONNECTION
CONNEXION ANALOGIQUE 3,5mm VERS DOUBLE FICHE RCA • CONEXIÓN ANALÓGICA RCA DE 3.5mm A DOS RCA • 3,5mm ZU DOPPEL-CINCH-ANALOGKABEL • CONNESSIONE ANALOGICA CON JACK DA 3,5mm A DOPPIO JACK RCA CONEXÃO ANALÓGICA DE 3,5mm •
PARA RCA DUPLO • 3.5mm 转双 RCA 模拟连接
3.5mm TO DUAL RCA CABLES
NOT INCLUDED
8
Small Yellow Tip
Small Yellow Tip
Petit embout jaune
Punta pequeña amarilla
Kleine gelbe Spitze
Punta gialla piccola
Ponta amarela pequena
黄色细端

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Klipsch R-4B and is the answer not in the manual?

Klipsch R-4B Specifications

General IconGeneral
Product colorBlack
RMS rated power- W
Recommended usageUniversal
Remotely operatedYes
Remote control typeWireless
Audio output channels- channels
Amplification device form factorBuilt-in
Speaker depth85.7 mm
Speaker width1016 mm
Speaker height88.9 mm
Satellite speaker type2-way
Satellite speaker weight2600 g
Number of satellite speakers1
Satellite speaker dimensions (WxDxH)1016 x 85.7 x 88.9 mm
Satellite speaker mid-range driver diameter2.5 \
Subwoofer depth360 mm
Subwoofer width160 mm
Subwoofer height255 mm
Subwoofer drivers quantity2
Subwoofer dimensions (WxDxH)160 x 360 x 255 mm
Subwoofer driver diameter (imperial)7.5 \
AirPlayNo
Acoustic amplification106 dB
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power sourceAC
Cables includedOptical
