Klutch 49413 - Parts List for Model 49417

Page 15 of 18
Parts List - 49417
Part No. Description Quantity
1 T Bolt Assembly M14*35 1
2 Spring Washer 14 1
3 Flat Washer 14 1
4 Hex Bolt M8*25 9
5 Connect Plate 1
6 Poly Drum 1
7 Hex Nut M10 4
8 Flat Washer 10 8
9 Hex Bolt M10*25 4
10 Spring Washer 10 4
11 Mixer Blade 2
12 Strengthen Plate 1
13 Spring Washer 10 9
14 Flat Washer 10 9
15 Hex Bolt M10 9
16 Frame Assembly 1
17 Hex Nut M8 2
18 Spring Washer 8 2
19 Flat Washer 8 2
20 Hex Bolt M8*45 2
21 Handle Sleeve 2
22 Hex Bolt 2
23 Hex Bolt M6*16 3
24 Flat Washer 6 3
25 Spring Washer 6 3
26 Hex Nut M6 3
27 Protect Nat 1
28 Flat Washer 6 5
29 Spring Washer 6 5
30 Hex Nut M6 5
31 Motor & Gearbox Assembly 1
32 Switch 1
33 Cord 1
34 Hex Bolt M12*70 2
35 Flat Washer 12 2
36 Wheel 2
37 Flat Washer 12 2
38 Hex Nut M12 2
