Step 1: Fix the screws from Part A onto board 1 , and put Part B into
the corresponding position (as per below diagram). Attach board 3 &
4 to board 1 , and then fix the round screws from Part A with a
screwdriver. Ensure all parts align.
Step 2: Slide board 10 into the corresponding position (as per below
diagram). Ensure it is fully fitted in the groove.
Step 3: Put part B in corresponding position (as per below diagram),
Attach board 2 with screws (Part C), using a screwdriver.
Step 4: Fix Part H onto board 2 with screws (Part G).
