11
11
11
11
10
D
D
7
8
9
6
A
A
A
5
Step 5: Screw the legs (Part 11 ) into Part H from step 4.
Step 6: Assemble board 6 , 7 , 8 with screws (Part D). Slide board 9
into corresponding position (as per below diagram). Ensure it is fully
fitted in the groove.
Step 7: Fix the screws from Part A onto board 5 . Attach this piece
to the part from step 6 (as per below diagram), and then fix the round
screws from Part A with a screwdriver. Ensure all parts align.
Step 8: Slide the drawer into the unit. Assembly is complete.
Note this drawer comes with wall fixing attachments ( E & F ).
Please use if you want to secure this drawer to the wall.
