PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware content list. If any part is missing or damaged, DO NOT attempt to assemble
the product.
Estimated Assembly Time: 4 minutes
Tools Required for Assembly (not included): 13 mm or adjustable wrench.
ASSEMBLY INSTRUCTIONS
UNPACKING
This product requires assembly.
1. Carefully remove the stand and all parts from the carton.
2. Separate all parts from the packing materials. Compare parts with the illustration on page 3 to make
sure all parts are found.
3. Do not discard the packing material until you have carefully inspected and satisfactorily operated the
stand.
PREPARING THE STAND
1. Lay the miter saw stand (D) top down on the floor with
the folded legs on top. Push in a leg locking pin and
rotate that leg up until the locking pin (I) clicks into
place.
To Next Page
