ASSEMBLY INSTRUCTIONS
7
Hardware Used
AA
x 4
M6 x 20 mm Bolt
B
1. Attach the cabinet handle (C) to
the bottom cabinet (B) using
M6 x 20 mm bolts (AA).
Note: The cabinet handle (C) can be
attached to either side of the bottom cabinet
(B), but must match the end where the
swivel casters with brake (D) will be
installed. The holes in bottom cabinet (B)
are tapped and do not require nuts.
Hardware Used
CC
x 16
M8 x 25 mm Bolt
EE
x 16
Washer
DD
x 16
Spring Washer
2. Ensure all cabinet drawers are securely
locked into place using the lock (GG) and
key (HH) on the bottom cabinet (B). Lay
the bottom cabinet (B) on its back using
the cardboard package materials to
protect the finish. Mount the two swivel
casters with brake (D) to the bottom
cabinet (B) using M8 x 25 mm bolts (CC),
spring washer (DD) and washer (EE).
Repeat this process for the fixed casters
(E) on the opposite side of the bottom
cabinet (B). Return the bottom cabinet (B)
to its upright position.
Note: Two people may be required to
complete this installation. The swivel casters
with brake (D) must be installed on the end of
the bottom cabinet (B) with the cabinet
handle (C). Do not over tighten the screws.
1
2
C
C
AA
AA
D
CC
EE
DD
B
B
B
D
E
