10
OPERATING INSTRUCTIONS
3. Variable-speed Trigger Switch
a. To turn the screwgun ON, press the variable-
speed trigger switch (E).
b. To turn it OFF, release the variable-speed
trigger switch.
c. The variable-speed trigger switch delivers
higher speed with increased trigger pressure
and lower speed with decreased trigger
pressure.
Lock-on Button
This screwgun is equipped with a lock-on button
(C), which is convenient for continuous driving for
extended periods of time.
a. To drive continuously, press and hold the variable-speed trigger switch (E) and then press
the lock-on button (C). Release the trigger switch.
b. To unlock the lock-on button and stop continuous driving, press the trigger switch again.
4. LED Worklight
The LED worklight (F), located on the foot of the
screwgun, will illuminate when the trigger switch
is depressed. This provides additional light on
the surface of the workpiece for operation in
lower-light conditions. The LED worklight will
automatically turn off approximately 10 seconds
after the trigger has been released.
a. The LED worklight will blink rapidly if the
tool has stopped working in order to protect
internal circuits; please wait for the tool to cool
down, at which point it can be started again.
b. The LED worklight will blink slowly to indicate
that the battery charge is very low.
5. Installing and Removing the Belt Clip
a. Remove the battery pack. from the tool.
b. Align the rib of the belt clip (I) with the hole on
the base of the driver.
c. Insert the screw (J) and tighten the screw
securely with a Phillips screwgun (not
included).
d. To remove the belt clip, use a Phillips
screwgun to loosen the screw holding the belt
clip to the driver.
3
4
F
5
J
I
E
C
