12
kobalttools.com
KNOW YOUR MOWER
PART DESCRIPTION QUANTITY
F Upper handle 1
G Lower handle 1
H Handle knobs 1
I Cam locks 1
J Height adjustment lever 1
K Battery door 1
L Safety lock-out button 1
M Bail lever 1
N Lower handle locks 1
O Rear discharge cover 1
P Battery release button 1
F
M
L
H
I
O
N
G
K
J
P
