ASSEMBLY INSTRUCTIONS
kobalttools.com
13. Pull back on collar at the other end of soft PVC
hose (N). Push rmly to connect hose. Twist
collar to secure. Conrm hose is locked into
power washer unit by slightly pulling on hose.
The hose is now securely attached.
12. Pull upward on latches that are located on
sides of lower frame (G). Once upper latch is
ush, push down until lower latch clicks into
place.
12
1
2
F
G
3
13
1
2
N
F
N
11
ASSEMBLY INSTRUCTIONS
11. To remove nozzle (E), pull back on collar of
lance (I) and pull out nozzle.
1
2
11
I
E
