4
PACKAGE CONTENTS
PART DESCRIPTION PART DESCRIPTION
A Bail switch (switch lever) L Support frame with holes
B Handle M Handle-adjustment knob
C Self-propel trigger N Side rail
D Safety button O Self-propel speed control lever
E Handle-locking clamp (2) P Rear-discharge door
F Lift handle Q Trailing shield
G Power Indicator R Cutting-height adjustment lever
H Battery-compartment cover S Side-discharge door
I Front wheel T Side-discharge chute
J Mower deck U Mulching insert
K Rear wheel V Grass bag
Safety Button
The safety button must be pressed down before the motor can be started.
Bail Switch
The bail switch is located on the upper handle of the mower. The switch engages and
disengages the motor/ blade.
WARNING
The bail switch and the safety button are safety devices. Never attempt to bypass their
operations.
Self-Propel trigger
Turns the self-propel function ON and OFF.
Self-Propel Speed control lever
Increases or decreases the self-propel speed by moving the control lever.
Handle-Locking Clamp
Locks/unlocks the side rails in the extended or the recessed position.
Side Rails
Can be extended and locked for operation or recessed for storage.
