KOBE CHX9130SQB-1 User Manual (English)

Questions and Answers:

A
Anthony RodriguezAug 18, 2025
Why is my KOBE CHX9130SQB-1 Range hood not venting out correctly?
- D
  Debra HughesAug 18, 2025
  There are several reasons why your KOBE range hood might not be venting correctly. It could be installed outside the manufacturer's recommended clearance (adjust the clearance between the range hood and cooktop to 26”-30”, or 30”-36” for island range hoods). Insufficient make-up air inside the house can also be a factor, so try opening a window. Obstacles in the duct work or using a pipe size smaller than suggested can also cause this issue. Make sure to remove any obstacles and change the ducting to the manufacturer's suggestion.
A
Aaron RiveraAug 20, 2025
What to do if KOBE Range hood motors and lights are not working after installation?
- O
  Omar KaneAug 20, 2025
  If the motors and lights aren't working on your KOBE range hood after installation, first ensure the circuit breaker and the unit's power are turned ON, and use a voltage meter to check the power supply. Also, check and tighten the wire connections. If the issue persists, the control panel might be defective and require replacement.
M
Michelle ChaseAug 23, 2025
How to fix KOBE CHX9130SQB-1 when the motor works but the lights don't?
- M
  Marissa HammondAug 23, 2025
  If the motor is working but the lights aren't on your KOBE range hood, the LED light fixture(s) may be defective and need replacing. Check the wire continuity from the Control Panel to the LED Driver to the LED light fixture(s), as the light wiring(s) may be loose. In some cases, a defective control panel may also be the cause and would need to be replaced.
J
Juan HensonAug 26, 2025
Why is my KOBE CHX9130SQB-1 vibrating?
- S
  Shawn MeyerAug 26, 2025
  If your KOBE range hood is vibrating, it could be due to a few reasons. The blower system might not be secure, so try tightening the turbine impeller/squirrel cage and air chamber. Another cause could be an unbalanced turbine impeller/squirrel cage, which would need replacing. Also, check the installation of the hood and tighten the mounting bracket to ensure the hood is secured in place.
S
smithjoshuaAug 27, 2025
What to do if lights are working, but motor(s) is not on KOBE Range hood?
- A
  Anna SantanaAug 27, 2025
  If the lights are working, but the motor(s) isn't on your KOBE range hood, the motor(s) may be defective and need replacement. It could also be due to defective capacitor(s), which would also need replacing. Another potential cause is a defective control panel, requiring replacement.
C
Clinton SnyderAug 30, 2025
Why is cold air coming into my home from KOBE Range hood?
- D
  devinriveraAug 30, 2025
  If cold air is coming into your home from the KOBE range hood, it could be due to a pipe connection that isn't properly sealed, so check the pipe installation. Also, the damper might not be properly installed or is missing from the installation. Installing the damper will help to eliminate air backflow.
J
Jennifer TranSep 1, 2025
Why is my KOBE Ventilation Hood not venting properly?
- A
  Amy JenningsSep 1, 2025
  Your KOBE Ventilation Hood might not be venting correctly due to several reasons. The clearance between the hood and cooktop may be outside the recommended range (26”-30” or 30”-36” for island hoods). Insufficient make-up air in the house can also be a factor, so open a window to improve performance. Obstacles in the ductwork or using a pipe size smaller than recommended can also cause this issue. Clear any blockages and change the ducting to the suggested size.
A
Amy GarciaSep 4, 2025
What to do if KOBE Ventilation Hood motors and lights not working after installation?
- C
  Carly HernandezSep 4, 2025
  If the motors and lights on your KOBE Ventilation Hood aren't working after installation, first ensure that the circuit breaker and the unit's power are turned on, using a voltage meter to check the power supply. Then, check and tighten the wire connections. If problems persist, the control panel may be defective and require replacement.
R
Richard ThompsonSep 6, 2025
How to fix KOBE Ventilation Hood when motor works but lights don't?
- K
  Katie CarrSep 7, 2025
  If the motor in your KOBE Ventilation Hood is working but the lights are not, the LED light fixture(s) may be defective and need replacing. Also, check the wire continuity from the processor board to the light transformer and then to the LED light fixture(s) because the light wiring(s) could be loose. If these steps don't resolve the issue, the control panel might be defective and should be replaced.
M
Michael WilsonSep 9, 2025
Why is my KOBE Ventilation Hood vibrating?
- A
  Ann DavisSep 9, 2025
  If your KOBE Ventilation Hood is vibrating, it could be due to a few reasons. First, check that the blower system is secure by tightening the turbine impeller/squirrel cage and air chamber. If the vibration continues, the turbine impeller/squirrel cage might be unbalanced and need replacement. Also, verify that the hood is securely mounted by checking the installation and tightening the mounting bracket.

KOBE CHX9130SQB-1 Specifications

General

Brand	KOBE
Model	CHX9130SQB-1
Type	Range Hood
Mount Type	Under Cabinet
Number of Motors	1
Width	30 inches
Maximum Airflow	750 CFM
Duct Size	6 inches
Speed Levels	3
Lighting	LED
Filter Type	Baffle
Venting Type	Ducted
Material	Stainless Steel
Color	Stainless Steel
Depth	22 inches
Control Type	Mechanical

Summary

Important Safety Instructions

General Fire, Shock, and Injury Prevention

Precautions to reduce risk of fire, electric shock, or personal injury during installation and operation.

Grease Fire Safety Procedures

Steps to follow to reduce the risk of personal injury during a range top grease fire.

Gas Leak and Electrical Safety

Actions to take if gas is detected and warnings about electrical hazards.

Components of Package

Package Contents Overview

Lists all components included in the range hood and optional duct cover packages.

Installation

Installation Measurement Guidelines

Calculations and tables for determining proper installation dimensions based on cabinet or wall mount.

Under Cabinet Installation

Step-by-step instructions for installing the hood under a cabinet, including vent options.

Wall Mount Installation

Instructions for wall-mounted installation, including duct cover and mounting bracket details.

Operating Instructions

Control Panel Operation

Explanation of the control panel buttons for fan speed, power, and light functions.

Maintenance

Hood Surface Cleaning

Guidelines for cleaning the range hood's exterior surfaces, emphasizing gentle methods.

Baffle Filter and Oil Tunnel Cleaning

Instructions for draining and cleaning baffle filters and oil tunnels, noting sharp edges.

Specifications

Technical Specifications Summary

Details on model size, materials, electrical consumption, dimensions, weight, and performance metrics.

Measurements & Diagrams

Installation Measurement Diagrams

Visual representations with dimensions for under cabinet and wall mount installation configurations.

Mounting Bracket Dimensions

Diagrams illustrating the dimensions of the hood mounting bracket and duct cover brackets.

Parts List

Component Parts Identification

A comprehensive list of all parts for the range hood and optional duct cover, including part numbers.

Exploded View of Components

An illustrated breakdown of the range hood and duct cover components for easy identification.

Circuit Diagram

Electrical Wiring Diagram

Schematic illustrating the electrical connections for motors, capacitor, control unit, and lights.

Trouble Shooting

Common Issues and Solutions

A guide to identify and resolve common operational problems with the range hood.

Warranty

Warranty Terms and Coverage

Details on the limited warranty periods, coverage, and exclusions for KOBE range hoods.

Warranty Service Request

Information on how to qualify for and request warranty service, including contact details.

Product Registration

Product Registration and Contact Information

Forms for product registration and contact details for warranty service, support, and product inquiries.

KOBE CHX9130SQB-1 User Manual
