Koblenz SP-2015 - Handle Parts List

-8-
Updated: ABRIL-2016
VIII. - HANDLE PARTS LIST SP-2015 AND SP-2815.
ITEM
No. PARTE
DESCRIPTION
SP-2015
SP-2815
1
46-3168-00-2
HANDLE ASSEMBLY
1
1
1-1
05-3975-9
HANDLE COVER
1
1
1-2
17-3782-4
HANDLE LABEL
1
1
1-3
12-0830-5
HANDLE GRIP
2
2
1-4
17-3677-6
RESET LABEL
1
1
1-5
01-1256-5
BOLT 10-24 X 3/4
2
2
1-6
38-0338-4
CIRCUIT BREAKER 2O A
1
1
1-7
01-1732-5
SCREW 8-32X1/2"
2
2
1-8
04-0271-9
STAR WASHER
2
2
1-9
02-0015-4
HEX NUT 10-24 NC
2
2
1-10
08-1857-5
SWITCH INSULATION
1
1
1-11
05-3536-9
SWICTH ACTUATOR SPACER
2
2
1-12
37-0225-5
DUST CONTROL GASKET
1
1
1-13
13-2209-8
SECURITY LOCK
1
1
1-14
01-0272-3
SCREW 6X1/2
1
1
1-15
01-0851-4
BOLT 6-32 X 1
2
2
1-16
04-0275-0
STAR WASHER .140/.145X.310X.020
2
2
1-17
04-0036-6
FLAT WASHER 3/4 X 1-1/4
1
1
1-18
12-0414-8
STAIN RELIEVE No 1244
1
1
1-19
11-0096-5
MOMENTARY SWITCH
1
1
1-20
10-0140-3
CONNECTOR
1
1
1-21
28-0958-0
SWITCH CABLE ASSEMBLY
1
1
1-22
05-4275-3
CORD HOOK
1
1
1-23
01-0870-4
BOLT 1/4-20X 1 3/4
2
2
1-24
23-0982-00-1
HANDLE ASSEMBLY
1
1
1-25
01-1769-7
BOLT 1/4-20X 1 1/4
2
2
1-26
12-0869-01-1
HANDLE GASKET
2
2
1-27
03-0593-8
NAIL GAUGE 9 LENGTH 2 1/2"
2
2
1-28
13-2205-6
SECURITY LOCK PISTON
1
1
1-29
13-2206-4
SECURITY LOCK BUTTON
1
1
1-30
13-2207-4
SECURITY LOCK HOUSING
1
1
1-31
13-2208-0
SECURITY LOCK COVER
1
1
1-32
05-3979-1
ON/OFF LEVER
1
1
1-33
24-0292-3
LEVER SPRING
3
3
1-34
01-1984-2
BOLT 8-32X7/8
2
2
1-35
04-0276-8
STAR WASHER No. 8
2
2
1-36
17-3988-7
(NEUTRAL) LABER
1
1
1-37
04-0493-9
INTERNAL TOOTH WASHER
1
1
1-38
01-0852-2
BOLT 8-32 X 3/8
1
1
1-39
12-0313-2
STRAIN RELIEF 1274
1
1
1-40
28-1078-6
LINE CORD
1
1
1-41
02-0092-3
NYLON NUT
4
4
1-42
12-0115-1
RUBBER STRAIN RELIEF
1
1
1-43
28-0672-7
MOTOR LINE CORD
1
1
1-44
04-0019-1
FLAT WASHER
2
2
1-45
12-1167-00-5
HEYCO CAP 2683
1
1
