Step 3: Put the "Rotary-CVR plate " to the "Stand-base" in its way properly, and make sure
that the holes of "Stand-post" and "Rotary CVR plate " are aligned rightly. and then
use the screwdriver to fix them together with provided screws.
Step 4: assemble finished.
5
Fig.3
ROTARY-CVR PLATE
SCREW
AV INPUT1 / INPUT2
1.Connect the composite outputs (Video, L & R) of VCR/DVD Player to AV INPUT 1 / INPUT2.
2.1 Press the Input button on the remote to select AV1/AV2.
AV Input-1
V
L R
AV Input-2
V
L
R
5. ANTENNA AND EXTERNAL CONNECTION EQUIPMENT
AV
AV
NOTE : Selecting a Source
Remote Control :
Press Input button on the remote control to display' Input source OSD'. Then choose any source by
pressing Up/Down button and Press Enter to select it.
TV Control Panel :
Press Source button and choose any source by pressing Prog+ / - button and Press source
button again to select it.
4. DESKTOP TV BRACKET INSTALLATION & ASSEMBLY
