4) Match the ends of the T-poles so that they are touching. Grasp both poles firmly and push down.
WARNING
Poles are under tension. Grasp poles firmly. Keep
face away from poles. Keep hands away from the
pole joint to avoid pinching.
5) Slide the metal brace over the pole joint until the push pins in the pole lock the sleeve into place.
NOTE: To disassemble, push the pin in to slide the brace away from the joint.
6) Join upright poles.
7) Unzip doors to allow air to enter. Raise the tent end and insert the end of the upright pole onto the
post on the bottom of the T-pole. Lift the pole and place pole bottom over the pin attached to the D-
ring at the bottom of the tent.
7
