(e) Place generator’s “no fuse breaker switch” in the “on” position.
Be sure to ground the generator if the connected electrical equipment is
grounded.
CAUTION: When the generator is overloaded or a short circuit is made,
the ‘no-fuse breaker” switch will stop the engine to protect the
circuit automatically. If the “no-fuse breaker” switch trips
during operation, the generator is either over loaded or the
appliance is defective.
Check the appliance and/or generator for overloading or
defect, make necessary corrections or repairs before use.
● Dual voltage type (SGB4000HX (S), SGB5500HX (S) SGB7000HX (S) only)
(a) Select the voltage using the “select” switch in accordance with the
electrical appliance. Refer to table below.
(b) Operate in the same way as single voltage type.
TABLE 1
SWITCH LOWER VOLTAGE RECEPTACLE HIGHER VOLTAGE RECEPTACLE
110V or 120V RATED OUTPUT IS AVAILABLE UNAVAILABLE
110V/220V or
120V/240V
HALF OF RATED OUTPUT IS
AVAILABLE
RATED OUTPUT IS AVAILABLE
● Battery charger (SGB4000HX (S), SGB5500HX (S) SGB7000HX (S) only)
The DC terminal is used only for charging 12 volt batteries. It provides up to 12V-8.3A
(100W) of maximum power.
CAUTION: Be sure to make correct connection to the battery. The positive (+)
battery terminal should be connected to the “red” terminal.
Do not over-charge the battery. Over-charging
of a battery can result in
personal injury due to explosion of battery.
STOPPING OPERATION
(Please refer to the Honda Owner’s manual)
MAN-GENef(12-99)
