A.1. CONTROL / SAFETY EQUIPMENT 3A. DEVICE PLACEMENT AND INSTALLATION PRINCIPLES2
DO THE INSTALLATION to a qualified firm according to the connection scheme that corresponds to the model of the
product you have purchased.
• Products are shipped with wooden pallets for transportation purposes. It should be disassembled before assembly.
• Fortheinstallationoftheproduct,itisnecessarytobuildabaseonasolid/stableoorwiththestrengthtobearthe
weight of the water heater.
• In the place where the product is to be installed,it is necessary to determine the location of the installation by providing
the necessary interventions and discharging fields that can be done in case of product breakdown or change.
• Your device should be placed in a closed or non-freezing location. Your product is designed for use at ambient
temperatures of + 5-50 degrees Celsius. Products used outside of this temperature range and outside conditions are
not covered by the warranty.
• In order for your product to be able to operate efficiently, the installation must be made exactly as indicated on the
scheme and the capacity of the heat sources must be selected according to the need for hot water. The product is not
covered by warranty due to inefficient operation or physical damage due to installation errors.
• The device is not covered by the warranty if the automatic type safety valve conforming to TS EN 1487: 2016 is not
installed, damaged or improperly.
• Precautionsshouldbetakenagainstthefireandoodontheareawheretheproductisinstalled.Ourcompanyisnot
responsible for any equipment malfunctions or contingency.
Safety equipment: To prevent the drinking water temperature from exceeding 95 ºC, the control and safety devices
must be installed and operated by the user according to the following order:
i) Thermostatic control device,
ii) Energy-cut device,
iii) Temperature, pressure relief valve / safety relief valve,
Safety Valve : In case of high pressure in the product, the water heater drains the water.
Expansion Tank : Itisusedtoregulatethepressureuctuationsthatcanoccurinthesystem.
Filter (dirt separator) : It is used to keep undesirable substances in the particle which may be present in the liquid
entering the system.
Valve : Itisusedasaninstallationelementthatallowswaterowinthesystemorstopstheow.
Pump : It is used to circulate the liquid used in the system.
Manometer : It is used to show the pressure value in the system.
Thermometer : It is used to see the temperature of the liquid in the system.
Pressure Reducer : It is absolutely necessary to install a pressure reducer in the connection line so that the water
pressure on the line does not rise above the maximum allowable pressure of the device.
Check Valve : Itallowstheliquidmovinginthesystemtoowinthedesireddirection,reverseowofliquidis
prevented.
