Kohler Command CH25

8.17
Section 8
Electrical System and Components
8
Ground-To-Kill Lead (White)
Diode
Key
Switch
Optional
Oil Sentry
TM
Switch
(Indicator Light)
Optional
Oil Sentry
TM
Switch
(Shutdown)
12 V. Battery
Solenoid
Starter
Lights
(Yellow)
(Black)
3 Amp/70 Watt
Flywheel Stator
Ignition
Modules
Spark
Plug
(Red)
(Blue)
RA
S
B
GND
Light
Optional
Fuse
Optional
Ammeter
Spark
Plug
1st Style
2nd Style
25 Amp Stator
Figure 8-21. 25 Amp Stator and Rectifier-Regulators.
3 Amp Unregulated Charging System
Figure 8-22. Wiring Diagram - 3 Amp Unregulated Battery Charging System/70 Watt Lighting.
