Kohler Command CH25

9.19
Section 9
Disassembly
9
Figure 9-73. Removing Crankshaft.
Remove Governor Cross Shaft
1. Remove the hitch pin and plain washer, or the
retainer and nylon washer from the governor
cross shaft. See Figures 9-74 and 9-75.
Remove Crankshaft
1. Carefully pull the crankshaft from the crankcase.
See Figure 9-73. Note thrust washers and shims
if used.
Figure 9-75. Removing Governor Cross Shaft
Retainer (8 mm Shaft Design).
2. Pull the cross shaft with small washer out
through the inside of the crankcase. See Figure
9-76.
Figure 9-74. Removing Governor Cross Shaft Hitch
Pin (6 mm Shaft Design).
Figure 9-76. Pulling Governor Cross Shaft.
Remove Flywheel End Oil Seal
1. Remove oil seal from crankcase. See Figure 9-77.
Figure 9-77. Removing Oil Seal.
