Clutch
General
Some engines are equipped with a “wet” disc type clutch. See Figure 12-1 for exploded view of clutch.
Figure 12-1. Wet Type Clutch - Exploded View.
Nameplate
Gasket
Shifting Lever
Seal
Shaft
(Yoke)
Clutch
Housing
Key
Yoke
Roll Pin
Ball Bearing
Power
Shaft
Adjusting
Ring
Driven
Member
Clutch
Assembly
Pilot Bearing
Pressure
Plate
Release
Sleeve
Clutch Assembly
Adjusting
Lock
Bearing Release
Assembly
Oil Seal
Retaining
Rings
Snap Ring
