4
Oil Fill/
Dipstick
Electric Starter
Breather Oil Separator
Air Cleaner Cover
Fuel Filter
Oil Filter
Oil Drain
Plug
Air Intake Screen
Blower Housing
Fuel Pump
Engine
Identification Label
Figure 1. Typical Command Vertical Shaft Carbureted Engine.
Oil Fill/Dipstick
Oil Cooler
Ignition Coil
Fuel Injector
Throttle Body Intake Manifold
Fuel
Injector
Ignition
Coil
Figure 2. Typical Command Vertical Shaft EFI Engine.
