TT-1702 10/16 5

3.4 Installation Drawings

Figure 3 Battery Charger Installation, GM96386-KP2 and GM96386-KP4

3, 4

GM96386-KP2

12 Volt Kit

GM96386-KP4, 24 Volt Kit

1. Bracket, GM28557

2. Battery charger, GM96383

3. Screw, M6

4. Nut, M6

5. Connect ring terminals to battery

6. Plug AC cord into outlet (after connecting to battery)

3, 4
